Jabsco HotShot 3 Washdown Pump (12V / 11LPM / 50PSI)
Jabsco HotShot 3 Washdown Pump (12V / 11LPM / 50PSI)
Couldn't load pickup availability
Limited Stock - Call 01484 482269
Jabsco HotShot 3 Washdown Pump (12V / 11LPM / 50PSI)
Part No: JAB-32305-5012
The Jabsco Xylem HotShot 3 12V DC is a reliable high-flow and high-pressure diaphragm washdown pump providing exceptional performance in an economical footprint.
Pump features include a plastic housing protecting the motors from corrosion, vibration-dampening feet for quiet operation and an integrated, sealed pressure switch for on-demand operation. It has a dry self-priming capability of 2.1 meters (7ft) and can run dry without damage.
The Jabsco Xylem HotShot 3 is supplied with quick connect straight hose barb and GHT fittings, an inline 40 mesh quick connect strainer, and trigger nozzle and quick connect hose adapters.
- Voltage: 12V DC
- Open flow GPM (LPM): 3 (11)
- Shut-off pressure PSI (BAR): 50 (3.4)
- Max. current AMPS: 7.5
- Recommended fuse size: 15
- Dimensions: 9.1" in length, 4.2" in width, 4.2" in height / 239(L) x 104(W) x 97(H)mm
Approvals
ISO 8846 Ignition Protected, C.E Certified, RCM compliant
Cut In Pressure
40 PSI
Cut Out Pressure Description
50 PSI / 3.4 Bar
Flow Rate Description
11 LPM (2.9 US GPM)
Fuse
15A (not included)
Height Description
97mm
Size
Leads: 12" (305mm), 16 AWG (1.5mm^2)
Supplied With
Inline Strainer (40 mesh) & Quick Connect Fittings - no hosecoil
Temperature Range
Ambient & Fluid: 0°C to 60°C (32°F ‐ 140°F)
Voltage Description
12V DC
Weight
2.61kg
Width
104mm
Brand
Jabsco
Model
32305-5012-3A
Pressure Rating
Operating: 50 PSI (3.4 bar) maximum, Inlet: 30 PSI (2.1 bar) maximum
Replaces
JAB-32305-0392
Self Primes up to
Up to 10ft (3m) dry prime
Inlet Outlet
Fittings for 13mm (1/2") ID hose, 19mm (3/4'') hose and US Garden Hose Thread
Amps Description
8 Amps at 50 PSI (3.4 BAR)
Depth
219mm
Share
View full details
Jabsco HotShot 3 Washdown Pump (12V / 11LPM / 50PSI)
Part No: JAB-32305-5012
The Jabsco Xylem HotShot 3 12V DC is a reliable high-flow and high-pressure diaphragm washdown pump providing exceptional performance in an economical footprint.
Pump features include a plastic housing protecting the motors from corrosion, vibration-dampening feet for quiet operation and an integrated, sealed pressure switch for on-demand operation. It has a dry self-priming capability of 2.1 meters (7ft) and can run dry without damage.
The Jabsco Xylem HotShot 3 is supplied with quick connect straight hose barb and GHT fittings, an inline 40 mesh quick connect strainer, and trigger nozzle and quick connect hose adapters.
- Voltage: 12V DC
- Open flow GPM (LPM): 3 (11)
- Shut-off pressure PSI (BAR): 50 (3.4)
- Max. current AMPS: 7.5
- Recommended fuse size: 15
- Dimensions: 9.1" in length, 4.2" in width, 4.2" in height / 239(L) x 104(W) x 97(H)mm
| Approvals | ISO 8846 Ignition Protected, C.E Certified, RCM compliant |
| Cut In Pressure | 40 PSI |
| Cut Out Pressure Description | 50 PSI / 3.4 Bar |
| Flow Rate Description | 11 LPM (2.9 US GPM) |
| Fuse | 15A (not included) |
| Height Description | 97mm |
| Size | Leads: 12" (305mm), 16 AWG (1.5mm^2) |
| Supplied With | Inline Strainer (40 mesh) & Quick Connect Fittings - no hosecoil |
| Temperature Range | Ambient & Fluid: 0°C to 60°C (32°F ‐ 140°F) |
| Voltage Description | 12V DC |
| Weight | 2.61kg |
| Width | 104mm |
| Brand | Jabsco |
| Model | 32305-5012-3A |
| Pressure Rating | Operating: 50 PSI (3.4 bar) maximum, Inlet: 30 PSI (2.1 bar) maximum |
| Replaces | JAB-32305-0392 |
| Self Primes up to | Up to 10ft (3m) dry prime |
| Inlet Outlet | Fittings for 13mm (1/2") ID hose, 19mm (3/4'') hose and US Garden Hose Thread |
| Amps Description | 8 Amps at 50 PSI (3.4 BAR) |
| Depth | 219mm |
