Victron Energy
Victron Multiplus 12/800/35 Combi Inverter Charger
Victron Multiplus 12/800/35 Combi Inverter Charger
Regular price
£757.27 GBP
Regular price
Sale price
£757.27 GBP
Taxes included.
Shipping calculated at checkout.
Enquiries: sales@allaboutboats.co.uk
Victron Multiplus 12/800/35 Combi Inverter Charger
Part No: VV-028
The MultiPlus, as the name suggests, is a combined inverter and charger in one elegant package. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology, plus multiple system integration features.
• 1600 Watt peak power
• 700 Watt/800VA continuous power
• 35A Battery charger
• 4A Float charge for starter battery
• 16A Transfer switch
• UPS Power Assist
• Dimensions (H x W x D) 375 x 214 x 110 mm
• Weight: 10 kgs
Application
FLA, SLA, AGM, GEL, LiFePO4 Batteries
Approvals
CE Certified
Capacity Description
Recommended Battery Capacity: 200 - 350 Ah
Charge Characteristic
Automatic, adaptive
Charge Current
35amp
Connection [AC]
ST-18i plug
Continuous Output
700w
Efficiency
93%
Height Description
375mm
Input
9.5v - 17v
Output
230 v ac
Peak Power
1600w
Rating
N/A
External Temperature Sensor
Yes
Voltage Description
9.5V - 17V DC, 230V AC
Weight
10kg
Width
214mm
Brand
Victron
Number of Outputs
1+ 4A float
Additonal Float Charge Output
4A
Optional Remote Panel
Yes, see data sheet
Cables Included
Yes, 1.5M DC
Output Frequency [Hz]
50
Output Power [W] Continuous
800
Output Power [W] Peak
1600
Waveform
True Sine Wave
Connection [DC]
8mm rings
Depth
110mm
Share
View full details
Victron Multiplus 12/800/35 Combi Inverter Charger
Part No: VV-028
The MultiPlus, as the name suggests, is a combined inverter and charger in one elegant package. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology, plus multiple system integration features.
• 1600 Watt peak power
• 700 Watt/800VA continuous power
• 35A Battery charger
• 4A Float charge for starter battery
• 16A Transfer switch
• UPS Power Assist
• Dimensions (H x W x D) 375 x 214 x 110 mm
• Weight: 10 kgs
| Application | FLA, SLA, AGM, GEL, LiFePO4 Batteries |
| Approvals | CE Certified |
| Capacity Description | Recommended Battery Capacity: 200 - 350 Ah |
| Charge Characteristic | Automatic, adaptive |
| Charge Current | 35amp |
| Connection [AC] | ST-18i plug |
| Continuous Output | 700w |
| Efficiency | 93% |
| Height Description | 375mm |
| Input | 9.5v - 17v |
| Output | 230 v ac |
| Peak Power | 1600w |
| Rating | N/A |
| External Temperature Sensor | Yes |
| Voltage Description | 9.5V - 17V DC, 230V AC |
| Weight | 10kg |
| Width | 214mm |
| Brand | Victron |
| Number of Outputs | 1+ 4A float |
| Additonal Float Charge Output | 4A |
| Optional Remote Panel | Yes, see data sheet |
| Cables Included | Yes, 1.5M DC |
| Output Frequency [Hz] | 50 |
| Output Power [W] Continuous | 800 |
| Output Power [W] Peak | 1600 |
| Waveform | True Sine Wave |
| Connection [DC] | 8mm rings |
| Depth | 110mm |
