Vetus
Vetus P104810 Foot Switch (Black with Grey / 12V & 24V)
Vetus P104810 Foot Switch (Black with Grey / 12V & 24V)
Couldn't load pickup availability
Limited Stock - Call 01484 482269
Vetus P104810 Foot Switch (Black with Grey / 12V & 24V)
Part No: V-P104810
The Vetus P104810 'Maxwell' foot switch is designed to operate an anchor windlass, but is also ideal for operating a bow thruster on a sailing yacht. On such boats it is often difficult to find a location for a conventional control panel, where it won't get damaged and is easily reached from behind the wheel.
The foot switch is operated via solenoids on 12 volt or 24 volt systems, allowing for smaller diameter wiring to be used. The compact up and down foot switch features a black protective cover to avoid accidental engaging of the solenoids.
The grey button is reversible to indicate the direction and can be operated by hand with the protective cover down or by foot when the cover is open.
Voltage Description
12V - 24V DC
Brand
Vetus
Diameter Description
65mm
Model
P104810
Replaces
The Vetus FSBG foot switch which replaced the AFSTFG.
Amps Description
150A Maximum
Depth
22mm (7/8")
Share
View full details
Vetus P104810 Foot Switch (Black with Grey / 12V & 24V)
Part No: V-P104810
The Vetus P104810 'Maxwell' foot switch is designed to operate an anchor windlass, but is also ideal for operating a bow thruster on a sailing yacht. On such boats it is often difficult to find a location for a conventional control panel, where it won't get damaged and is easily reached from behind the wheel.
The foot switch is operated via solenoids on 12 volt or 24 volt systems, allowing for smaller diameter wiring to be used. The compact up and down foot switch features a black protective cover to avoid accidental engaging of the solenoids.
The grey button is reversible to indicate the direction and can be operated by hand with the protective cover down or by foot when the cover is open.
| Voltage Description | 12V - 24V DC |
| Brand | Vetus |
| Diameter Description | 65mm |
| Model | P104810 |
| Replaces | The Vetus FSBG foot switch which replaced the AFSTFG. |
| Amps Description | 150A Maximum |
| Depth | 22mm (7/8") |
