UL Certified Four Core Tinned Round Cable White (14AWG / 30m Coil)
UL Certified Four Core Tinned Round Cable White (14AWG / 30m Coil)
Couldn't load pickup availability
Limited Stock - Call 01484 482269
UL Certified Four Core Tinned Round Cable White (14AWG / 30m Coil)
Part No: 733413-E
UL approved four core round tinned cable 14AWG
Our UL approved tinned four core round cable is designed for boats and the marine environment. The outer jacket is extruded onto the finely stranded ABYC (Type III) tinned copper wire conductors, filling the voids to make the wiring cable robust and durable, yet easy to strip. Round jacket wiring cables allow for easy installation where tight corners and turns are common. The outer can be more easily sealed in a cable gland. The tinned cable features a round, white outer cable sheath with the specification printed on and is resistant to: acid, alkalis, abrasion, flame, petrol, diesel, oils and moisture.
Our tinned UL wiring cable complies with: UL standard 1426, ABYC: E-11.16, USCG: 33 CFR part 183 and NMMA.
Approvals
Complies with: UL standard 1426, ABYC: E-11.16, USCG: 33 CFR part 183 & NMMA.
Size
14 AWG
Temperature Range
-20°C to +105°C dry (75°C wet)
Voltage Description
Max. 600V DC
Brand
ASAP Electrical
Style
UL Approved Cable
Cable Conductor
Tinned Copper
Cable Cores
4 Core
Colour
White
Unit of Sale
30 Metres
Cable Inner Colours
Black, Red, Green & White
Conductor Specifications
41/0.100
Cable Conductor Cross Section Description
2.08mm²
Diameter Description
Nominal OD: 10.16mm (0.4")
Shape Description
Round
Share
View full details
UL Certified Four Core Tinned Round Cable White (14AWG / 30m Coil)
Part No: 733413-E
UL approved four core round tinned cable 14AWG
Our UL approved tinned four core round cable is designed for boats and the marine environment. The outer jacket is extruded onto the finely stranded ABYC (Type III) tinned copper wire conductors, filling the voids to make the wiring cable robust and durable, yet easy to strip. Round jacket wiring cables allow for easy installation where tight corners and turns are common. The outer can be more easily sealed in a cable gland. The tinned cable features a round, white outer cable sheath with the specification printed on and is resistant to: acid, alkalis, abrasion, flame, petrol, diesel, oils and moisture.
Our tinned UL wiring cable complies with: UL standard 1426, ABYC: E-11.16, USCG: 33 CFR part 183 and NMMA.
| Approvals | Complies with: UL standard 1426, ABYC: E-11.16, USCG: 33 CFR part 183 & NMMA. |
| Size | 14 AWG |
| Temperature Range | -20°C to +105°C dry (75°C wet) |
| Voltage Description | Max. 600V DC |
| Brand | ASAP Electrical |
| Style | UL Approved Cable |
| Cable Conductor | Tinned Copper |
| Cable Cores | 4 Core |
| Colour | White |
| Unit of Sale | 30 Metres |
| Cable Inner Colours | Black, Red, Green & White |
| Conductor Specifications | 41/0.100 |
| Cable Conductor Cross Section Description | 2.08mm² |
| Diameter Description | Nominal OD: 10.16mm (0.4") |
| Shape Description | Round |
