SHURflo Aqua King II Premium 4.0 Fresh Water Pump (12V / 55 PSI)
SHURflo Aqua King II Premium 4.0 Fresh Water Pump (12V / 55 PSI)
Couldn't load pickup availability
SHURflo Aqua King II Premium 4.0 Fresh Water Pump (12V / 55 PSI)
Part No: 509622
The SHURflo Aqua King II Premium 4148 series fresh water pump design was created with unique over-moulded single-piece diaphragm and internal bypass, assuring long life and top performance in all plumbing systems.
The boat water pump is designed as the next legendary fresh water pump to exceed the expectations of customers. The SHURflo Aqua King II series pumps are constructed for high flow demand, smooth flow and no rapid cycling using the latest reaction technology. The automatic demand fresh water pumps are also quiet, thermally protected and can run dry without damage
SHURflo has built their quality reputation on the reliability and dependability of every pump they build, and with the upgraded Aqua King they have built a pump with the same footprint as the old model to allow for easy retrofitting.
SHURflo Marine Water Pump Features & Benefits
- Supplied complete with strainer and fittings.
- Co-moulded diaphragm.
- 4 independent chambers.
- Adjustable switch and bypass.
- Multi-fixture, up to 4 fixtures.
- Self-priming up to 6 feet.
- Run dry capability.
- Sealed switch.
- Sealed motor.
- Corrosion resistant electro coated motor.
- Thermally protected.
- Ignition protected, CE.
- 1 Year warranty.
Approvals | Ignition Protected 8846, CE Listed |
Cut Out Pressure Description | 55 PSI / 3.8 Bar, Bypass Shut-Off Pressure: 65 PSI / 4.5 Bar |
Flow Rate Description | 15.1 LPM (4 US GPM) |
Fuse | 15A |
Height Description | 120mm (4.7") |
Length | 254mm (10") |
Series | Aqua King II Premium |
Supplied With | Strainer |
Type | Fresh Water Pumps |
Voltage Description | 12V DC |
Width | 127mm (5") |
Brand | SHURflo |
Accumulator Recommended | No |
Warranty | 3 Years |
Hose Size | 13mm / 1/2" |
Model | 4148-153 |
Replaces | Pressure Pumps: 509530 Shurflo Smart Sensor 4.0, 509512 Shurflo Aqua King Premium 4.0 4901-4212 & 509830 Whale IC Galley Pump |
Self Primes up to | 1.82 Metres (6 Feet) |
Inlet Outlet | Fittings for 13mm (1/2" NPSM Male) ID hose |
Amps Description | 10A Maximum |
