R&D Drive Plate For ZF & PRM (10 Teeth Spline / 215.9mm Diameter)

Part No: RND-22W60

22W60 R & D Marine Gearbox Damper Drive Plate

Fitted between the engine and the gearbox input shaft, a damper drive plate is designed to transmit the engine power to the gearbox, whilst reducing transmitted gear noise and providing a cushioned drive when selecting gear. All R and D Damper Drive plates include a 'failsafe' design.

Also called the Driven Plate, Damper Plate or Clutch Plate, the 22W60 Damper Drive Plate is from the R and D Hammer Head element range. Common applications for the 22W60 drive plate include Kubota engines with Beta SAE 6.5 flywheel fixing.

Marine drive plate technical details:

- Spline: 10 teeth B10 x 23 x 29 DIN 5464 (29mm diameter)

- For gearbox types Newage PRM 80, 120 & 150 gearbox, ZF 10, 12, Hurth HBW5, 10, 35, 50, 100, 125 & 15 gearboxes, Technodrive TMC 30, 40, 50 & 60 gearboxes and Borgwarner 500

- Diameter of back plate which bolts to the engine flywheel: 215.9mm (8.5") SAE 6.5

- Back plate has 6 fixing holes: 6 x 8.1mm on 200 mm PCD, SAE 6.5"

- Drive plate maximum thickness: 32mm (1.25")

Fitted with the multi-directional 'W' Hammer Head element for 135 Nm 100 ft lb torque, providing a smaller element diameter which is more torsionally flexible than the loop type elements and provides three stage stiffness with up to 9 degrees of deflection. These damper drive plates are also fail safe.

If you are unsure or need any assistance choosing your drive plate please contact our customer support department who will help you find the right parts for your application.
