Quick DP2 1012D Windlass Gypsy & Drum (1000W / 12V / 8mm)
Quick DP2 1012D Windlass Gypsy & Drum (1000W / 12V / 8mm)
Regular price
£2,521.46 GBP
Regular price
£2,101.22 GBP
Sale price
£2,521.46 GBP
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
Limited Stock - Call 01484 482269
Quick DP2 1012D Windlass Gypsy & Drum (1000W / 12V / 8mm)
Part No: Q2DP2191203
The Quick DP2 Prince 1012D vertical windlass is suitable for boats from 8m to 13m (26 to 43ft). The vertical mount windlass is easy to install with an AISI 316 Stainless Steel base and fitted with the new 100% recyclable technopolymer gearbox. Featuring an integrated sensor and magnet for chain counter and a manual free-fall system. The Quick windlass features a 8mm (5/16") gypsy which is suitable for 8mm ISO chain and a 1/2" rope. This version also comes with a drum attached.
Height Description
294.4mm (11-19/32")
Series
Prince DP2
Voltage Description
12V DC
Wattage
Motor Power: 1000W
Weight
15.1kg (33lb) without drum
Brand
Quick
Primary Construction
Stainless Steel
Suitable For
Chain and Rope
Maximum Pull Load
930kg (2050 lb)
Contents
Contactor Units, Nylon Handle, Drilling Template, User Manual
Model
1012D Mk2
Replaces
Quick FSDP21012D08A00
Boat Size
8 to 13 metres in length
Gypsy Size
8mm
Amps Description
Current Absorbtion At Working Load: 130A
Depth
219.5mm (8-41/64")
Share
View full details
Quick DP2 1012D Windlass Gypsy & Drum (1000W / 12V / 8mm)
Part No: Q2DP2191203
The Quick DP2 Prince 1012D vertical windlass is suitable for boats from 8m to 13m (26 to 43ft). The vertical mount windlass is easy to install with an AISI 316 Stainless Steel base and fitted with the new 100% recyclable technopolymer gearbox. Featuring an integrated sensor and magnet for chain counter and a manual free-fall system. The Quick windlass features a 8mm (5/16") gypsy which is suitable for 8mm ISO chain and a 1/2" rope. This version also comes with a drum attached.
| Height Description | 294.4mm (11-19/32") |
| Series | Prince DP2 |
| Voltage Description | 12V DC |
| Wattage | Motor Power: 1000W |
| Weight | 15.1kg (33lb) without drum |
| Brand | Quick |
| Primary Construction | Stainless Steel |
| Suitable For | Chain and Rope |
| Maximum Pull Load | 930kg (2050 lb) |
| Contents | Contactor Units, Nylon Handle, Drilling Template, User Manual |
| Model | 1012D Mk2 |
| Replaces | Quick FSDP21012D08A00 |
| Boat Size | 8 to 13 metres in length |
| Gypsy Size | 8mm |
| Amps Description | Current Absorbtion At Working Load: 130A |
| Depth | 219.5mm (8-41/64") |
