Maestrini DZR Brass Anti-Siphon Loop (3/4" BSP / 1/2" BSP Vent)
Part No: 410064
This Maestrini anti-siphon device is made from DZR brass (corrosion resistant brass). The anti-siphon device allows fluid to flow in the intended direction but when the flow is reversed, the vacuum will operate the anti-siphon valve which will break the siphoning effect. This anti-siphon loop is used in conjunction with 410073 siphon break valve.
Typical applications for this anti-siphon loop are boat water intakes, exhaust injection lines and toilet systems where installed equipment is below the waterline.
Height Description
93mm (3.7")
Material
Corrosion Resistant (CR), Dezincification Resistant Brass (DZR)
Width
121mm
Brand
Maestrini
Primary Construction
DZR / CR Brass
Thread Connection
BSP
Thread Fitting Size
3/4"
Thread Gender
Female
Valve Design
Siphon Break Valve
Country of Origin
Italy
Connections Description
Port Size: 3/4" BSP Female, Vent Pipe: 1/2" BSP Female
Pressure Rating
580 PSI (40 Bar)
Thread Size
3/4" BSP Female
Depth
37mm
Share
View full details
Maestrini DZR Brass Anti-Siphon Loop (3/4" BSP / 1/2" BSP Vent)
Part No: 410064
This Maestrini anti-siphon device is made from DZR brass (corrosion resistant brass). The anti-siphon device allows fluid to flow in the intended direction but when the flow is reversed, the vacuum will operate the anti-siphon valve which will break the siphoning effect. This anti-siphon loop is used in conjunction with 410073 siphon break valve.
Typical applications for this anti-siphon loop are boat water intakes, exhaust injection lines and toilet systems where installed equipment is below the waterline.
| Height Description | 93mm (3.7") |
| Material | Corrosion Resistant (CR), Dezincification Resistant Brass (DZR) |
| Width | 121mm |
| Brand | Maestrini |
| Primary Construction | DZR / CR Brass |
| Thread Connection | BSP |
| Thread Fitting Size | 3/4" |
| Thread Gender | Female |
| Valve Design | Siphon Break Valve |
| Country of Origin | Italy |
| Connections Description | Port Size: 3/4" BSP Female, Vent Pipe: 1/2" BSP Female |
| Pressure Rating | 580 PSI (40 Bar) |
| Thread Size | 3/4" BSP Female |
| Depth | 37mm |
