Johnson Aquajet Water Pressure Pump (12V / 20LPM / 41 PSI)



Part No: 10-13406-07

Johnson Aquajet water pressure pump suitable for providing fresh water to taps, showers and the galley of a boat, or equally provide domestic water for a recreational vehicle or caravan. This is the WPS 5.2 model of the Aquajet series, containing 5 chambers and featuring a simple to service design. It is recommended the pump is used in conjunction with an accumulator tank and fitted with a PUMProtector inlet strainer.

The pump features a santoprene diaphragm suitable for contact with fresh water. The body is made from polypropylene and valves from EPDM rubber.

Johnson 10-13406-07 Spare Parts:

Spare Part | Part Number

Pressure Switch | 09-46781-01

Pump Head Kit | 09-47284-02

Fittings (3/4" Hose) | 09-46939

T-Fittings | 09-46907

Filter BSP | 09-24653-02

Filter NPT | 09-24653-02

Accumulator Tank | 09-46839-02

Rubber Bellow Accumulator Tank | 0.2770.241

Rubber Feet | 09-46908

Fitting Retainer | 09-47278

Approvals ISO 8846 MARINE (Ignition protection), CE Listed Cut Out Pressure Description 41 PSI / 2.8 Bar Flow Rate Description 20 LPM (5.3 US GPM) Fuse 15A Height Description 110mm (4.3") Length 240mm (9.4") Material PP Body, EPDM Valves & Santoprene Diaphragm Series Aquajet WPS 5.2 Type Fresh Water Pumps Voltage Description 12V DC Wattage Motor: 150W Weight 2kg Width 214mm (8.4") Brand Johnson Accumulator Recommended Yes Warranty 3 Years Hose Size 13mm / 1/2", 19mm / 3/4" Model 10-13406-07 Self Primes up to 2.5 Metres (8.2 Feet) Inlet Outlet Fittings for 13mm (1/2") and 19mm (3/4") ID hose plus 3/8" BSP and 1/2" BSP
