Johnson 10-24886-01 Electric Motor Pump (12V / 14 LPM / 13mm Hose)
Johnson 10-24886-01 Electric Motor Pump (12V / 14 LPM / 13mm Hose)
Couldn't load pickup availability
Johnson 10-24886-01 Electric Motor Pump (12V / 14 LPM / 13mm Hose)
Part No: 10-24886-01
The Johnson 10-24886-01 electric motor pump is suitable for 12 volt systems and can pump 14 litres per minute and self primes up to 1.5 metres. The Johnson pump features a nitrile impeller (JP-09-1077B-9) and has a thermoplastic polyester construction. This electric motor pump has barb connections that are suitable for 13mm (1/2") inside diameter hose.
This is a multi-purpose impeller pump suitable for applications including: bilge, deck wash and shower tray draining among others.
Johnson 10-24886-01 Spare Parts:
Position | Spare Part | Part Number
1 | Body | 01-24885
2 | Motor (12V) | 01-35285-01
3 | Impeller | 09-107B-9
4 | Lip Seal | 0.2233.007
5 | End Cover | 01-45739-2
6 | O-Ring | 0.2172.506
7 | Screw | 0.0145.009
8 | Nut | 0.0185.309
9 | Washer | 0.0353.301
10 | Slinger | 0.2173.470
12 | Foot Kit | 09-47194
13 | Wear Plate | 01-47524
| Service Kit | 09-47582
| Approvals | ISO8846 marine (ignition), ISO8849 marine (bilge pump), ISO10133 Small Craft (Low voltage DC Installations) standards. |
| Flow Rate Description | 900LPH (240 US GPH) |
| Flow Rate 1 Metre Head | 870 LPH (228 US GPH) (at 1.8m Head: 840 LPH (222 US GPH)) |
| Fuse | 16A |
| Height Description | 78mm (3.1") |
| Length | 172mm (6.8") |
| Voltage Description | 12V DC |
| Wattage | Power: 0.12kW |
| Width | 117mm (4.6") |
| Brand | Johnson |
| Automatic Bilge Pumps | No |
| Flow Rate 3 Metre Head | 810LPH (216 US GPH) |
| Flow Rate 6 Metre Head | 660LPH (174 US GPH) |
| Hose Size | 13mm / 1/2" |
| Model | 10-24886-01 |
| Replacement Impeller | JP-09-1077B-9 |
| Replaces | Johnson Pump 10-24180-01 |
| Self Primes up to | 1.5 Metres (4.9 Feet) |
| Inlet Outlet | For 13mm (1/2") ID Hose |
| Amps Description | 7.2A |
