Jabsco HotShot HD6 Washdown Pump (12V / 23LPM / 70PSI)
Part No: JAB-P601J-219N-3A
A 12V DC high-flow, high-pressure diaphragm washdown pump from Jabsco Xylem. This HotShot HD6 heavy duty model features a wide diameter motor (compared to standard non-HD models) with a powder-coated shell, cast aluminium endbells and lower housing to improve pressure capability and life.
The pump has vibration-dampening feet for quiet operation and an integrated, sealed pressure switch for on-demand operation. It has a dry self-priming capability of 2.1 meters (7ft) and can run dry without damage.
The Jabsco Xylem HotShot HD6 is supplied with quick connect straight hose barb and GHT fittings, a 90° 20 mesh quick connect strainer and trigger nozzle and quick connect hose adapters.
- Voltage: 12V DC
- Open flow GPM (LPM): 6 (23)
- Shut-off pressure PSI (BAR): 70 (4.8)
- Max. current AMPS: 19.0
- Recommended fuse size: 25
- Dimensions: 10.2" in length, 5.1" in width, 4.7" in height / 259(L) x 129(W) x 119(H)mm
| Approvals | ISO 8846 Ignition Protected, C.E Certified, RCM compliant |
| Cut In Pressure | 50 PSI |
| Cut Out Pressure Description | 70 PSI / 4.8 Bar |
| Flow Rate Description | 23 LPM (6 US GPM) |
| Fuse | 25A (not included) |
| Height Description | 119mm |
| Size | Leads: 12" (305mm), 14 AWG (2.5mm^2) |
| Supplied With | Inline Strainer (40 mesh) & Quick Connect Fittings - no hosecoil |
| Temperature Range | Ambient & Fluid: 0°C to 60°C (32°F ‐ 140°F) |
| Voltage Description | 12V DC |
| Weight | 8.06kg |
| Width | 129mm |
| Brand | Jabsco |
| Model | P601J-219N-3A |
| Pressure Rating | Operating: 70 PSI (3.4 bar) maximum, Inlet: 30 PSI (2.1 bar) maximum |
| Replaces | JAB-82605-0092 |
| Self Primes up to | Up to 7ft (2.1m) dry prime |
| Inlet Outlet | Fittings for 13mm (1/2") ID hose and US Garden Hose Thread |
| Amps Description | 19 Amps at 70 PSI (4.8 BAR) |
| Depth | 260mm |
