Jabsco Flange Mounted Engine Cooling Pump 23430-1001 (32mm Ports)

Part No: JAB-23430-1001

Jabsco flexible impeller flange mounted raw water engine cooling pump 23430-1001 is made of bronze.

Jabsco 23430-1001 engine cooling pump engine applications:

- Aifo Iveco 8280 M and 8281 SRM

- Nanni Diesel OM 366, 4.220 HE, 5.280 HE and 6.280

- Mitsubishi S 6E2

- Schwarting Mercedes S 616 and 617A

- Sole Diesel MB 616-4 and MB 616-6

- VM-Motori HR Series

The Jabsco engine cooling pump is renowned for its reliability and engine cooling efficiency. To ensure your Jabsco pumps work as the manufacturer intended it is strongly advised to use only genuine Jabsco pump impellers and pump spares.

Jabsco Pump 23430-1001 Spare Parts:

Part ID | Spare Parts | Part Number | Quantity

1 | Screw | SP1003-0111 | 6

2 | End Cover | 11831-0000 | 1

3 | Gasket | 890-0000 | 1

4 | Cam | 934-0000 | 1

5 | Screw (3 Pack) | 91004-0090 | 1

6 | Spline Plug (3 Pack) | 4345-0000 | 1

7 | Impeller & Gasket Kit | 17937-0001-P | 1

10 | Wearplate | 4156-0000 | 1

12 | Seal | SP2700-1027B | 1

13 | Spacer | 23431-0000 | 1

18 | O-Ring | X4020-215A | 1

20 | Seal | SP2700-1027B | 1

21 | Bearing | SP2600-01 | 2

26 | Shaft | 23437-0000 | 1







Size	080 Pump
Type	Engine Cooling Pumps
Brand	Jabsco
Suitable For	Mercruiser
Warranty	1 Year
Model	23430-1001
Mounting Description	Flange Mount
Repair Kit	SK385-0001
Replacement Impeller	JAB-17937-0001-P
Inlet Outlet	32mm (1-1/4")
