Jabsco Engine Cooling Pump 29500-1501 (28mm Hose / Flange Mount)

Part No: JAB-29500-1501

The Jabsco 29500-1501 flexible impeller engine cooling pump has a bronze body with a long stainless steel shaft.

Jabsco Pump 29500-1501 suits engines:

- Beta Marine BV1903, BV 2203 and BF 2803 engines

- Kubota V1903 and V2203 engines

When ordering the Jabsco 29500-1501 pump, we recommend adding a replacement impeller, use part number: JAB-1210-0001-P - always carry a spare!

Jabsco 29500-1501 Pump Spare Parts:

Part ID | Spare Part | Part Number | Quantity

1 | Spline Plug (3 Pack) | 4345-0000 | 1

2 | Impeller & Gasket Kit | 1210-0001-P | 1

3 | End Cover | 11830-0000 | 1

4 | Screw (3 Pack) | 91002-0020 | 6

6 | Gasket | 3298-0000 | 1

7 | Cam | 490-0001 | 1

8 | Screw (3 Pack) | 91003-0010 | 1

9 | Wear Plate | 7883-0000 | 1

10 | Spacer | 23431-0000 | 1

11 | O-Ring | X4020-215A | 1

12 | Seal | SP2700-1027B | 2

13 | Bearing | SP2601-0451B | 2

14 | Shaft | 29516-0000 | 1

| Service Kit | SK384-0001 | 1
