Jabsco 59520-0000 Water Circulation Pump (8V - 24V)
Jabsco 59520-0000 Water Circulation Pump (8V - 24V)
Regular price
£547.58 GBP
Regular price
£456.32 GBP
Sale price
£547.58 GBP
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
Limited Stock - Call 01484 482269
Jabsco 59520-0000 Water Circulation Pump (8V - 24V)
Part No: 209520
Jabsco 59520 circulation pump is made from non-corroding materials and is very efficient with a low power consumption. This Jabsco circulation pump is quiet and maintenance free, with a long life of up to 30,000 hours. The circulation pump has a "brush-less" DC motor along with a "seal-less" magnetic drive pump. The Jabsco 59520 is a compact, effective and quiet pump that has a variable flow rate with 5 settings. This water circulation pump operates in system pressures up to 10 bar and is suitable for hot water systems and water glycol mixtures.
Application
Handles aggressive liquids
Approvals
Meets EMC Requirements & Ignition protected (ISO8846 MARINE)
Consumption
Adjustable: 0.25A - 1.7A (maximum)
Flow Rate Description
26 LPM (6.8 US GPM) at 0.10 bar (1.45 psi)
Fuse
2.5A
Height Description
86mm (3-3/8")
Length
90mm
Series
59520 Series
Supplied With
Mounting Bracket
Temperature Range
Circulates water up to 80°C
Voltage Description
12V DC & 24V DC, Range: 8V to 24V DC
Width
82mm
Brand
Jabsco
Connections Description
1/2" BSP Female
Continuously Rated
Yes
Model
59520-0000
Pressure Rating
Up to 10 bar
Inlet Outlet
1/2" BSP Female Ports
Amps Description
1.8A
Share
View full details
Jabsco 59520-0000 Water Circulation Pump (8V - 24V)
Part No: 209520
Jabsco 59520 circulation pump is made from non-corroding materials and is very efficient with a low power consumption. This Jabsco circulation pump is quiet and maintenance free, with a long life of up to 30,000 hours. The circulation pump has a "brush-less" DC motor along with a "seal-less" magnetic drive pump. The Jabsco 59520 is a compact, effective and quiet pump that has a variable flow rate with 5 settings. This water circulation pump operates in system pressures up to 10 bar and is suitable for hot water systems and water glycol mixtures.
| Application | Handles aggressive liquids |
| Approvals | Meets EMC Requirements & Ignition protected (ISO8846 MARINE) |
| Consumption | Adjustable: 0.25A - 1.7A (maximum) |
| Flow Rate Description | 26 LPM (6.8 US GPM) at 0.10 bar (1.45 psi) |
| Fuse | 2.5A |
| Height Description | 86mm (3-3/8") |
| Length | 90mm |
| Series | 59520 Series |
| Supplied With | Mounting Bracket |
| Temperature Range | Circulates water up to 80°C |
| Voltage Description | 12V DC & 24V DC, Range: 8V to 24V DC |
| Width | 82mm |
| Brand | Jabsco |
| Connections Description | 1/2" BSP Female |
| Continuously Rated | Yes |
| Model | 59520-0000 |
| Pressure Rating | Up to 10 bar |
| Inlet Outlet | 1/2" BSP Female Ports |
| Amps Description | 1.8A |
