Bowman FC100 Hydraulic Oil Cooler (1" BSP Oil / 1" BSP Water)
Bowman FC100 Hydraulic Oil Cooler (1" BSP Oil / 1" BSP Water)
Regular price
£526.88 GBP
Regular price
Sale price
£526.88 GBP
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
Bowman FC100 Hydraulic Oil Cooler (1" BSP Oil / 1" BSP Water)
Part No: 203340
Bowman FC100 hydraulic oil cooler heat exchanger is also suitable to be used for heat transfer fluids, lubricating and quenching oils.
Typical Example of oil cooler performance with an oil outlet temperature of 50°C and water inlet temperature of 25°C:
- Hydraulic oil flow: 145 LPM
- Cooling water flow: 135 LPM
- Heat dissipated: 19 kW
- Oil Pressure Drop: 100 kPa
- Head Loss: 50 kPa
| Height Description | 130mm (5-1/8") |
| Length | 358mm |
| Width | 126mm |
| Brand | Bowman |
| Country of Origin | United Kingdom |
| Connections Description | Oil & Water: 1" BSP Female |
| Cooling Water Flow | 140 LPM (exceeding maximum flow may cause tube failure) |
| Dimensions | Distance between fixing hole centres: 190mm x 76mm |
| Fixing Hole Size | M8 x 12 |
| Hydraulic Oil Flow | 145 LPM Maximum (based on Shell Tellus 37 at 60°C) |
| Internal Oil Volume | 1.10 Litres |
| Internal Water Volume | 0.84 Litres |
| Maximum Pressure | 20 bar at 120°C |
| Model | FC100-1426-2 |
| Pressure Drop | Oil: 100 kPa |
| Raw Water Flow | 80 LPM (exceeding maximum flow may cause tube failure) |
