Bowman EC160 Hydraulic Oil Cooler (3/4" BSP Oil / 3/4" BSP Water)
Part No: 203316
Bowman EC160 hydraulic oil cooler heat exchanger is also suitable to be used for heat transfer fluids, lubricating and quenching oils.
Typical Example of oil cooler performance with an oil outlet temperature of 50°C and water inlet temperature of 25°C:
- Hydraulic oil flow: 64 LPM
- Cooling water flow: 66 LPM
- Heat dissipated: 22 kW
- Oil Pressure Drop: 100 kPa
- Head Loss: 50 kPa
Height Description | 105mm (4.1") |
Length | 572mm |
Width | 100mm |
Brand | Bowman |
Country of Origin | United Kingdom |
Connections Description | Oil & Water: 3/4" BSP Female |
Cooling Water Flow | 80 LPM (exceeding maximum flow may cause tube failure) |
Dimensions | Distance between fixing hole centres: 416mm x 52mm |
Fixing Hole Size | M6 x 10 |
Hydraulic Oil Flow | 64 LPM Maximum (based on Shell Tellus 37 at 60°C) |
Internal Oil Volume | 1.30 Litres |
Internal Water Volume | 0.91 Litres |
Maximum Pressure | 20 bar at 120°C |
Model | EC160-1425-5 |
Pressure Drop | Oil: 100 kPa |
Raw Water Flow | 50 LPM (exceeding maximum flow may cause tube failure) |
